Can You Drill Holes in Floor Joists for Plumbing?

If you’re planning a bathroom remodel, kitchen upgrade, or adding new plumbing lines, you’ve probably wondered: Can you drill holes in floor joists for plumbing? The short answer is yes—but only if you follow critical building codes and engineering guidelines. Drilling in the wrong spot or making a hole too large can weaken your home’s structure, leading to sagging floors or even costly repairs. In this guide, we’ll walk you through exactly how to do it safely, legally, and effectively.

Why Drilling Floor Joists Requires Caution

Floor joists are horizontal structural members that support your floors—and everything on them. They’re engineered to handle specific loads, and any modification (like drilling) can compromise their strength if done incorrectly.

According to the International Residential Code (IRC), which governs most U.S. home construction, there are precise rules about where and how large you can drill holes in joists. Ignoring these isn’t just risky—it may violate local building codes and void your home insurance.

💡 Expert Insight: “A hole in the wrong location can reduce a joist’s load-bearing capacity by up to 40%,” says structural engineer Maria Lopez, P.E., of the American Society of Civil Engineers (ASCE).

Where Can You Safely Drill Holes in Floor Joists?

Not all parts of a joist are created equal. The key is to drill in the neutral axis—the area of the joist under the least stress.

✅ Safe Zone:

• Location: Center third of the joist’s depth (vertically).
• Distance from ends: At least 2 inches from the top or bottom edge.
• Distance from supports: Holes must be at least 2 feet away from the ends or bearing points.

❌ Danger Zones:

• Within 2 inches of the top or bottom edge.
• Within 2 feet of where the joist connects to a beam or wall.
• Near existing notches, cracks, or previous modifications.

For a standard 2×10 joist (actual depth: 9.25 inches), the safe drilling zone is roughly between 3.1 and 6.1 inches from the bottom.

Maximum Hole Size: What the Codes Allow

The IRC sets clear limits based on joist depth:

⚠️ Note: Holes cannot exceed 1/3 of the joist’s depth. For a 2×10, that’s ~3.1 inches—perfect for most 2-inch plumbing pipes (which actually measure ~2.375″ OD with insulation).

For engineered I-joists, rules differ. Always consult the manufacturer’s specs—some allow larger holes in the web, while others prohibit field drilling entirely.

Step-by-Step: How to Drill Holes for Plumbing Safely

Follow this checklist to stay compliant and structurally sound:

1. Turn off water and power in the work area.
2. Locate joists using a stud finder or by removing a small section of subfloor.
3. Measure and mark the center third of the joist depth.
4. Verify clearance: Ensure the hole is ≥2 ft from supports and ≥2″ from top/bottom edges.
5. Choose the right drill bit: Use a spade bit or hole saw sized for your pipe (e.g., 2.5″ for 2″ PVC).
6. Drill straight and level—angled holes reduce structural integrity.
7. Install pipe with proper supports every 4–6 feet to prevent sagging.
8. Inspect and document: Take photos for your records or future home inspections.

🔧 Pro Tip: If multiple pipes are needed, stagger holes in adjacent joists rather than drilling several holes in one joist.

What If You Can’t Drill? Alternative Solutions

Sometimes, drilling isn’t feasible—especially in older homes with smaller joists or in load-bearing zones. Consider these alternatives:

• Run pipes through walls or ceilings instead of floors.
• Use smaller-diameter PEX tubing (½” or ¾”) which requires smaller holes.
• Install a soffit or bulkhead to hide plumbing below the joists.
• Sister a new joist alongside the existing one to share the load if modification is unavoidable.

For complex layouts, consult a licensed structural engineer. The cost ($200–$500) is minor compared to fixing a collapsed floor.

Real-World Example: Bathroom Remodel Gone Right

In a 2023 Portland, OR renovation, homeowner James T. needed to reroute a 2″ drain line for a new shower. His 2×10 joists were spaced 16″ apart.

He:

• Drilled 2.75″ holes in the center third of each joist.
• Kept holes 24″ from end supports.
• Used PVC pipe with proper slope (¼” per foot).
• Had the work inspected by the city—passed on first try.

Result? A code-compliant, leak-free bathroom with no floor deflection.

Common Mistakes to Avoid

• Drilling near the edge: Creates stress concentration → cracks.
• Oversized holes: Weakens joist beyond repair.
• Ignoring local codes: Some cities (like Chicago or NYC) have stricter rules than IRC.
• Skipping permits: Unpermitted plumbing work can derail home sales.

For more on structural wood design principles, see Wikipedia’s entry on Joists .

FAQ Section

Q1: Can I drill a hole in the top or bottom of a floor joist?

No. The top and bottom edges are under high compression and tension. Drilling there drastically reduces strength. Always stay in the center third.

Q2: How many holes can I drill in one joist?

The IRC allows multiple holes, but they must be spaced at least 2x the hole diameter apart and not aligned vertically with holes in adjacent joists unless engineered otherwise.

Q3: Can I notch a joist instead of drilling?

Notching is more dangerous than drilling. Notches are only allowed at the ends (max ¼ depth) and never in the middle third. Drilling is preferred for plumbing runs.

Q4: Do I need a permit to drill joists for plumbing?

Yes, in most U.S. jurisdictions. Any structural modification or new plumbing typically requires a permit and inspection. Check with your local building department.

Q5: Can I drill through engineered I-joists?

Only if the manufacturer allows it. Many I-joists have pre-punched knockouts in the web. Never drill outside designated zones—doing so voids warranties and risks failure.

Q6: What pipe material is best for running through joists?

PEX is ideal—it’s flexible, requires smaller holes, and resists freezing. For drains, PVC or ABS (2″–3″) are standard but need larger holes and proper slope.

Conclusion

So, can you drill holes in floor joists for plumbing? Absolutely—if you respect the rules. By drilling in the right location, using the correct hole size, and following code guidelines, you can safely install plumbing without jeopardizing your home’s structure.

Doing it right protects your investment, ensures safety, and keeps inspectors happy. If in doubt, hire a licensed plumber or structural engineer—it’s worth the peace of mind.
