How Big Are Spaces for Plumbing in 3 5/8 Studs?

If you’re planning a bathroom remodel, installing new fixtures, or running pipes through interior walls, you’ve probably asked yourself: “How big are spaces for plumbing in 3 5/8 studs?” You’re not alone. Many DIYers and contractors struggle with fitting modern plumbing into standard wall cavities—especially when working with narrower studs like the common 3 5/8-inch metal or wood studs used in US residential construction. In this guide, we’ll break down exactly how much usable space you have, what fits (and what doesn’t), and how to stay compliant with building codes—all while keeping your project efficient and leak-free.

What Exactly Is a “3 5/8 Stud”?

Before diving into plumbing space, let’s clarify what a 3 5/8 stud actually means. Despite the name, this measurement refers to the actual width of a standard metal or wood stud used in non-load-bearing interior walls—not its nominal size.

• Nominal vs. Actual Dimensions: A “2×4” wood stud is actually 1.5″ x 3.5″. But in commercial or multi-family residential builds, 3 5/8-inch metal studs are extremely common. These are measured by their actual flange-to-flange depth.
• Wall Thickness: When drywall (typically ½” thick) is installed on both sides, a wall framed with 3 5/8″ studs ends up being about 4 5/8 inches thick total.

💡 Pro Tip: Always measure your actual cavity—not just rely on stud labels. Variations in drywall thickness or insulation can reduce usable space.

According to the International Residential Code (IRC), plumbing must be installed without compromising structural integrity or fire ratings—especially in walls shared between units.

How Much Usable Space Is There for Plumbing?

Now, the core question: How much room do you really have inside a 3 5/8 stud wall for pipes?

Let’s do the math:

But wait—this assumes no insulation, vapor barriers, or electrical wiring. In reality:

• Insulation (e.g., fiberglass batts): adds ~0.25–0.5″
• Electrical boxes or NM cables: may protrude into the cavity
• Fireblocking or soundproofing: further reduces space

✅ Realistic usable depth for plumbing: ~3.0 to 3.25 inches

This might seem tight—but it’s often enough for standard residential plumbing if planned correctly.

What Pipe Sizes Fit Comfortably in a 3 5/8 Stud Wall?

Not all pipes are created equal. Here’s what typically fits:

📌 Expert Insight: “In narrow stud bays, I always recommend PEX over rigid copper or PVC for supply lines—it’s flexible, easier to snake through tight spaces, and requires fewer fittings,” says Mark Delaney, licensed master plumber with 18 years of experience in NYC high-rises.

For drain-waste-vent (DWV) systems, 1.5″ is often the practical max in 3 5/8 walls unless you furr out the wall or use shallow-depth fixtures (like wall-hung toilets with in-wall carriers).

Building Code Requirements You Must Know

Plumbing isn’t just about fitting pipes—it’s about safety, accessibility, and code compliance.

Key IRC & UPC (Uniform Plumbing Code) rules:

1. Stud Notching Limits:
   • Wood studs: Notches can’t exceed 25% of the stud width in load-bearing walls, 40% in non-load-bearing.
   • Metal studs: Never notch—use pre-punched knockout holes or drill carefully within manufacturer specs.
2. Protection Plates:
   If pipes are within 1.25″ of the edge of a stud, you must install steel nail plates to prevent accidental punctures during future work (IRC R602.6).
3. Drain Slope:
   DWV pipes need ¼” per foot of fall. In tight walls, ensure your vertical drop aligns with this—even a slight miscalculation can cause slow drainage or clogs.
4. Clearance for Valves & Access Panels:
   Shut-off valves and cleanouts must remain accessible. Plan for removable access panels behind vanities or in closets.

For more on standard dimensions in construction, see Wikipedia’s entry on dimensional lumber, which explains why actual vs. nominal sizes differ—a frequent source of confusion.

Step-by-Step: Installing Plumbing in a 3 5/8 Stud Wall

Follow this checklist to avoid costly rework:

1. Confirm Stud Type:
   Use a stud finder to determine if you’re working with metal or wood. Metal studs often have pre-punched holes at 24″ intervals.
2. Map Existing Utilities:
   Scan for electrical wires, HVAC ducts, or existing pipes using a multi-scanner. Never drill blindly.
3. Choose Flexible Supply Lines:
   Opt for ½” or ¾” PEX-A with expansion fittings. It bends around obstacles and needs less space than rigid pipe.
4. Drill Holes Strategically:
   • For wood studs: Drill centered holes (max 1.5″ diameter for 3.5″ depth).
   • For metal studs: Use knockout holes or drill only in the web (not flanges) with a metal-cutting bit.
5. Insulate Hot Water Lines:
   Prevent condensation and heat loss by wrapping hot PEX with closed-cell foam—just ensure total diameter stays under 1″.
6. Pressure-Test Before Closing Walls:
   Fill system to 80 PSI, hold for 2 hours. Any drop = leak. Fix it now—not after drywall!

Pros and Cons: Plumbing in Narrow Stud Walls

FAQ Section

Q1: Can I run a toilet drain in a 3 5/8 stud wall?
A: Yes—but only if you use a 1.5″ or 2″ wall-hung toilet carrier designed for shallow walls. Standard floor-mounted toilets with 3″ drains usually require a 2×6 (5.5″) wall.

Q2: Do metal studs affect plumbing installation?
A: Yes. Metal studs can’t be notched, and sharp edges may damage PEX over time. Always use plastic grommets or protective sleeves where pipes pass through metal studs.

Q3: What’s the minimum distance between plumbing and electrical wires?
A: The NEC doesn’t specify exact separation, but best practice is to cross at 90-degree angles and maintain at least 1 inch of separation to reduce interference and physical contact.

Q4: Can I install a shower valve in a 3 5/8 wall?
A: Most standard shower rough-in valves (like Moen or Delta) fit, but verify depth specs first. Some thermostatic valves require up to 4″ of cavity depth—pushing the limit.

Q5: Is insulation required around plumbing in interior walls?
A: Not usually for interior walls in climate zones 1–4. But in cold climates or exterior walls, insulating hot/cold lines prevents freezing and energy loss.

Q6: What if my pipe doesn’t fit?
A: Options include:

• Furring out the wall with ½” plywood
• Using surface-mount conduit (for exposed industrial looks)
• Switching to smaller-diameter alternatives (e.g., 1.25″ drain for sinks)

Conclusion

Understanding how big spaces for plumbing in 3 5/8 studs really are can save you time, money, and frustration. While the usable cavity is tight—roughly 3 to 3.25 inches—you can successfully run supply lines and even modest drains with smart planning, flexible materials like PEX, and strict adherence to code.

Whether you’re a weekend warrior or a seasoned pro, always measure twice, pressure-test early, and prioritize accessibility. Your future self (or the next homeowner) will thank you.
