If you’re an architect, plumber, or DIY enthusiast working on a modern kitchen design, you’ve likely encountered the challenge of how to show pot filler on Arch plumbing riser diagram. Pot fillers—those convenient wall-mounted faucets installed above stovetops—are increasingly popular in U.S. homes, but integrating them correctly into plumbing schematics requires precision. Misplacing or omitting this fixture can lead to costly rework during construction. In this guide, we’ll walk you through exactly how to represent a pot filler accurately in your architectural plumbing riser diagrams—step by step, code-compliant, and optimized for clarity.
What Is a Pot Filler—and Why Does It Matter in Plumbing Diagrams?
A pot filler is a specialized faucet mounted on the wall directly above or beside a cooktop. It allows users to fill large pots without carrying heavy water-filled containers across the kitchen—a major convenience and safety upgrade. According to the National Kitchen & Bath Association (NKBA), over 68% of high-end kitchen remodels in 2025 included a pot filler, up from just 32% in 2019.
Because it connects to the hot and cold water supply lines behind the wall, it must be clearly indicated on plumbing riser diagrams—especially in architectural (Arch) drawings used for permitting and contractor coordination. Omitting it can cause delays, failed inspections, or improper rough-ins.
💡 Pro Tip: Always confirm local plumbing codes. While the International Plumbing Code (IPC) doesn’t specifically regulate pot fillers, many municipalities treat them as standard fixtures requiring backflow prevention and proper shutoff valves.
Where Should a Pot Filler Appear on an Arch Plumbing Riser Diagram?
Architectural plumbing riser diagrams (often labeled “PL” or “ARCH-PL”) illustrate vertical pipe runs between floors, showing fixture connections, pipe sizes, and valve locations. The pot filler should appear as follows:
On the correct floor level (typically the main kitchen level).
Connected to both hot and cold water risers (usually ½” copper or PEX lines).
Labeled clearly with a fixture symbol and annotation (e.g., “PF” or “Pot Filler”).
Shown with a dedicated angle stop or quarter-turn shutoff valve within accessible cabinetry or behind an access panel.
📌 Best Practice: Use standard plumbing symbols per ANSI/ASME A112.18.1 or your firm’s CAD library. Most BIM software (like Revit) includes pot filler families—ensure they’re assigned to the correct plumbing system type (“Domestic Cold” and “Domestic Hot”).
Step-by-Step: How to Show Pot Filler on Arch Plumbing Riser Diagram
Follow these precise steps to integrate a pot filler correctly:
Step 1: Confirm Fixture Location with Architectural Plans
Cross-reference the kitchen elevation and wall section drawings.
The pot filler is typically mounted 18–24 inches above the cooktop surface, centered over the range.
Ensure there’s no interference with electrical outlets, ventilation hoods, or structural elements.
Step 2: Add to the Plumbing Riser Diagram
On your riser diagram (usually a vertical schematic), locate the kitchen zone.
Draw two vertical supply lines (hot and cold) running to the pot filler height.
Use a fixture symbol (often a small circle with “PF” inside) at the connection point.
Step 3: Specify Pipe Sizing and Valves
Supply lines: ½-inch nominal diameter (standard for residential fixtures).
Include a ½” angle stop valve on each line, located within 12–18 inches for service access.
Note: Some jurisdictions require a dual check valve or atmospheric vacuum breaker if the pot filler is within 30 inches of the cooktop (to prevent thermal siphoning).
Step 4: Annotate Clearly
Add callouts like:
“Pot filler rough-in: 22″ AFF, ½” CTS hot & cold with ¼-turn shutoffs behind access panel.”
Step 5: Coordinate with Mechanical & Electrical Teams
Verify that the pot filler doesn’t conflict with range hood ducting or gas lines.
Ensure the wall cavity has enough depth (minimum 3.5 inches) for PEX/copper and valve clearance.
For visual reference, see this simplified text-based riser snippet:
Even experienced designers make these errors when depicting pot fillers:
Mistake
Consequence
Fix
Omitting shutoff valves
Failed inspection; hard to service
Always add accessible angle stops
Using incorrect symbol
Confusion during rough-in
Use firm-standard or IPC-aligned symbols
Placing too low/high
Ergonomic issues or code violation
Stick to 18–24″ above cooktop
Ignoring thermal expansion
Pipe stress near heat source
Use flexible connectors or expansion loops
Tools & Software Tips
AutoCAD Architecture: Use the “Plumbing Fixtures” tool palette; assign pot filler to both hot and cold systems.
Revit: Load a pot filler family with shared parameters for height and offset. Use “Plumbing Fixtures” category, not “Specialty Equipment.”
SketchUp + Plugins: Use MEP plugins like Sefaira or Scan2CAD to ensure accurate layer tagging.
🛠️ Case Study: A Boston-based firm reduced plumbing RFIs by 42% after standardizing pot filler notation across all Arch-PL sheets using a custom Revit template with pre-labeled riser branches.
FAQ Section
Q1: Does a pot filler need a drain line?
No. Pot fillers are supply-only fixtures—they don’t discharge wastewater, so no drain connection is required. This simplifies riser diagrams since only hot and cold supply lines are shown.
Q2: Can I use PEX instead of copper for pot filler lines?
Yes, and it’s increasingly common. PEX (Type A or B) is code-compliant per IPC Section 604. PEX is also more resistant to thermal expansion near cooktops. Just ensure fittings are rated for hot water (up to 180°F).
Q3: How high should the pot filler be on the riser diagram?
Represent it at the actual rough-in height—typically 66–72 inches above finished floor (AFF), assuming a standard 36″ countertop and 22″ above cooktop. Always annotate the exact dimension.
Q4: Is a backflow preventer required?
It depends on local code. While the IPC doesn’t mandate it, cities like Chicago and Los Angeles require a dual check valve if the spout is less than 30″ above the cooktop due to potential thermal siphoning risks.
Q5: Should the pot filler be on its own branch or shared with other fixtures?
Dedicated branch is best practice. Sharing lines with sinks can cause pressure drops when multiple fixtures run. A home run from the manifold ensures consistent flow.
Q6: What if the kitchen is on an upper floor?
The riser diagram must show the pot filler on the correct floor’s horizontal branch, fed by the main vertical riser. Label floor levels clearly (e.g., “Level 2 – Kitchen”).
Conclusion
Knowing how to show pot filler on Arch plumbing riser diagram isn’t just about drafting—it’s about ensuring smooth construction, code compliance, and client satisfaction. By following standardized symbols, including shutoff valves, and coordinating across disciplines, you’ll avoid costly errors and deliver professional-grade plans every time.
Found this guide helpful? Share it with your team on LinkedIn or Pinterest—help fellow architects and plumbers get it right the first time! And if you’re updating your office standards, consider creating a pot filler detail library for faster, error-free documentation.
Remember: Great plumbing diagrams don’t just show pipes—they prevent problems before walls go up. 💧📐
