If your home relies on a private well, knowing how to plumb a well pump and pressure tankis essential for consistent, clean water flow. Many homeowners face issues like low water pressure, pump cycling, or leaks—often due to improper plumbing. Whether you’re installing a new system or troubleshooting an old one, this guide walks you through every critical step with clarity and confidence.
Why Proper Plumbing Matters for Your Well System
A well pump and pressure tank work as a team: the pump draws water from the well, and the tank stores it under pressure to deliver water on demand without the pump running constantly. Poor plumbing disrupts this balance, leading to:
Premature pump failure (the #1 cause of well system breakdowns, per the National Ground Water Association)
According to the U.S. Environmental Protection Agency (EPA), over 13 million U.S. households depend on private wells—making reliable plumbing not just convenient, but critical for health and safety.
Tools and Materials You’ll Need
Before you begin, gather these essentials:
✅ Tools:
Pipe wrench
Teflon tape (PTFE)
Adjustable wrench
Pipe cutter or hacksaw
Screwdrivers
Pressure gauge
✅ Materials:
1″ or 1¼” PVC or galvanized steel pipe (size depends on your system)
Check valve
Pressure switch
Air valve (Schrader valve)
Dielectric union (if connecting copper to steel)
Pressure tank (pre-charged to 2 psi below cut-in pressure)
💡 Pro Tip: Always turn off power to the pump at the circuit breaker before starting. Safety first!
Step-by-Step: How to Plumb a Well Pump and Pressure Tank
Follow these precise steps to ensure a leak-free, efficient setup.
Step 1: Install the Check Valve
Mount a spring-loaded check valve directly on the pump’s discharge outlet (submersible) or just after the jet pump. This prevents backflow into the well, which can cause pump cycling and contamination.
📌 Note: Never install a second check valve above ground—this can trap pressure and damage the system. The NGWA strongly advises against multiple check valves.
Step 2: Connect the Discharge Pipe
Run a straight, short pipe from the pump to the pressure tank. Use 1¼” pipe for flows over 10 GPM to reduce friction loss. Keep bends minimal—each 90° elbow adds resistance equivalent to 5–10 feet of straight pipe.
Step 3: Mount the Pressure Tank
Place the tank on a level, stable surface near the pump control box. Leave 6–12 inches of clearance around it for maintenance. Secure it with brackets if needed.
Step 4: Plumb the Tank Inlet
Connect the discharge pipe to the tank’s inlet using a union fitting for easy future removal. Wrap all threaded connections with 3–5 wraps of Teflon tape, clockwise.
Step 5: Install the Pressure Switch
Mount the pressure switch on a tee fitting between the pump and tank. This switch senses pressure and turns the pump on/off. Standard residential settings:
Cut-in: 40 psi
Cut-out: 60 psi
Use a pressure gauge next to the switch to monitor system performance.
Step 6: Pre-Charge the Tank
Before connecting water, check the tank’s air charge with a tire gauge at the Schrader valve (like a bike tire). It should be 2 psi below the cut-in pressure (e.g., 38 psi for a 40/60 system). Adjust with an air compressor if needed.
Verify the pump shuts off at cut-out pressure (e.g., 60 psi).
Run water—pump should restart near cut-in (e.g., 40 psi).
If the pump cycles rapidly, the tank may be waterlogged—replace the bladder or tank.
Common Mistakes to Avoid
Skipping the check valve
Backflow, pump damage
Install one at pump outlet
Over-tightening fittings
Cracked threads, leaks
Hand-tight + 1–2 wrench turns
Ignoring air pre-charge
Short cycling
Recharge tank annually
Using undersized pipe
Low pressure, noise
Match pipe to GPM demand
Well Pump vs. Pressure Tank: Roles Explained
Well Pump: Moves water from underground (typically 100–400 ft deep) to your home. Types: submersible (most common) or jet pumps.
Pressure Tank: Stores 20–80 gallons of pressurized water. Reduces pump starts from ~300/day to ~50/day, extending pump life by years.
⚠️ Fact: A properly sized pressure tank can extend pump lifespan by 5–10 years, saving $1,000+ in replacements (Water Systems Council).
FAQ: Your Top Questions Answered
Q1: How far should the pressure tank be from the well pump?
A: Ideally within 5–10 feet. Longer distances increase pipe friction and delay pressure response, causing unnecessary pump cycling.
Q2: Can I use PEX pipe for well pump plumbing?
A: Not recommended for the main discharge line. PEX can’t handle high temperatures or constant pressure surges near the pump. Use PVC, CPVC, or galvanized steel instead. PEX is fine for household distribution after the pressure tank.
Q3: Why is my pressure tank waterlogged?
A: The internal bladder ruptured or the air charge leaked. Symptoms: pump cycles every few seconds. Fix: Replace the tank—it’s rarely repairable.
Q4: What size pressure tank do I need?
A: Depends on pump flow rate (GPM). Rule of thumb:
10 GPM → 20-gallon tank
15 GPM → 40-gallon tank
20+ GPM → 80-gallon tank Check manufacturer charts for exact drawdown capacity.
Q5: Do I need a permit to install a well pump system?
A: Yes, in most states. Contact your local health or environmental department. Improper installation can risk groundwater contamination.
Q6: How often should I maintain the system?
A:
Check air charge: annually
Inspect fittings for leaks: every 6 months
Test water quality: yearly (EPA recommendation for private wells)
Conclusion
Learning how to plumb a well pump and pressure tankcorrectly saves money, prevents emergencies, and ensures your household has reliable water 24/7. With the right tools, clear steps, and attention to detail, even beginners can achieve professional results.
🔧 Did this guide help you? Share it with a neighbor, DIY friend, or on social media! Clean water starts with smart plumbing—and you just took a big step toward mastering it.
Got questions? Drop them in the comments below—we’re here to help!
