Are you remodeling your kitchen or installing a new sink in Illinois? Understanding the Il Plumbing Code On Cleanout Tees Under Kitchen Sink is essential to avoid costly violations and ensure proper drainage maintenance. Many homeowners struggle with confusing regulations, but this comprehensive guide will clarify everything you need to know about compliant cleanout installation under your kitchen sink.
What Does Illinois Plumbing Code Require for Kitchen Sink Cleanouts?
The Illinois Plumbing Code has specific requirements that differ from general national standards. According to local amendments, all residential kitchen sinks require a minimum two-inch (2″) waste opening with a two-inch (2″) cleanout
codelibrary.amlegal.com. This requirement ensures adequate access for clearing blockages and maintaining your drainage system.
Key Size Requirements
| Component | Minimum Requirement |
|---|---|
| Waste Opening | 2 inches |
| Cleanout Size | 2 inches |
| Clearance Space | 18 inches for rodding |
The cleanout must match the pipe size it serves, up to a maximum of 6 inches
www.law.cornell.edu. For residential kitchen applications, this means your 2-inch drain line requires a corresponding 2-inch cleanout fitting.
Where Should Cleanout Tees Be Installed Under Kitchen Sinks?
Proper placement is crucial for both code compliance and practical maintenance access. The Illinois Plumbing Code mandates that every cleanout shall be installed so that the cleanout opens in a direction opposite to the flow of the drainage line or at right angles thereto
www.law.cornell.edu.
Installation Direction Guidelines
- Opposite to flow: The cleanout opening faces upstream
- Right angle: Perpendicular to the drainage direction
- Accessibility: Must allow easy tool insertion for snaking
This orientation prevents debris from blocking the cleanout access point and makes it easier for plumbers to insert drain snakes or hydro-jetting equipment when needed.
How Much Clearance Is Required Around Cleanout Tees?
One of the most overlooked requirements involves clearance space. All cleanouts shall have a clearance of 18 inches for the purpose of rodding
www.law.cornell.edu. This isn’t just a suggestion—it’s a mandatory code requirement that affects your cabinet design and sink placement.
Why 18 Inches Matters
Without adequate clearance, you cannot properly:
- Insert standard drain cleaning tools
- Perform routine maintenance
- Address emergency clogs efficiently
- Meet inspection requirements
When designing your under-sink cabinetry, ensure the cleanout location maintains this 18-inch working space. Consider pull-out drawers or removable panels if space is limited.
Are Cleanouts Required on All Kitchen Sink Installations?
The answer depends on your specific setup and distance from the main drain connection. According to Illinois plumbing guidelines, cleanouts are required at any fixture more than 6 feet from the drain line connection
terrylove.com.
When Cleanouts May Not Be Required
- Fixtures within 6 feet of existing cleanouts
- Direct connections to accessible main lines
- Certain grandfathered installations
However, even when not strictly required by distance, installing a cleanout under your kitchen sink is considered best practice. Kitchen drains handle food particles, grease, and other materials prone to causing blockages, making regular maintenance access invaluable.
Step-by-Step Guide to Installing Compliant Cleanout Tees
Follow these detailed steps to ensure your installation meets Illinois plumbing code requirements:
Materials Needed
- 2-inch PVC or ABS cleanout tee (matching existing pipe material)
- Appropriate solvent cement or mechanical couplings
- 2-inch cleanout plug with gasket
- Pipe cutter or saw
- Measuring tape
Installation Process
Step 1: Measure and mark the location on your horizontal drain line, ensuring it’s downstream from the P-trap but accessible with 18 inches of clearance.
Step 2: Cut the existing drain pipe using a pipe cutter for a clean, square cut. Remove any burrs from the cut edges.
Step 3: Dry-fit the cleanout tee to verify proper orientation—the cleanout opening should face opposite the flow direction or at a 90-degree angle.
Step 4: Apply primer and solvent cement to both the pipe ends and fitting sockets (for PVC/ABS systems).
Step 5: Insert the cleanout tee, rotating slightly to distribute cement evenly. Hold firmly for 30 seconds.
Step 6: Install the cleanout plug with its rubber gasket, hand-tightening plus a quarter turn with a wrench.
Step 7: Allow the joint to cure according to manufacturer specifications—typically 2 hours for initial set and 24 hours for full strength.
Step 8: Test the installation by running water through the sink and checking for leaks at all connections.
Common Mistakes to Avoid
Many DIYers and even some contractors make these critical errors:
❌ Using Undersized Cleanouts
Installing a 1.5-inch cleanout on a 2-inch drain line violates code requirements and limits maintenance effectiveness.
❌ Insufficient Clearance
Placing cleanouts behind permanent fixtures or in tight corners without the required 18-inch working space.
❌ Wrong Orientation
Facing the cleanout in the direction of flow instead of opposite or perpendicular, making tool insertion difficult.
❌ Poor Accessibility
Installing cleanouts behind fixed shelving or requiring disassembly of cabinets for access.
Understanding the Purpose of Cleanout Tees
Cleanout tees serve as access points for clearing blockages in your drainage system. Without them, plumbers would need to remove traps, disconnect pipes, or use less effective methods to address clogs.
According to industry experts, properly installed cleanouts can reduce maintenance time by up to 70% and significantly lower service costs over the lifetime of your plumbing system. They’re particularly important for kitchen sinks, which handle:
- Food particles and scraps
- Grease and oil buildup
- Soap scum accumulation
- Mineral deposits from hard water
For more information about drainage system standards, you can reference general plumbing principles at Wikipedia’s Drain-Waste-Vent System page.
Differences Between Residential and Commercial Requirements
Illinois distinguishes between residential and commercial kitchen installations:
| Aspect | Residential | Commercial |
|---|---|---|
| Minimum Waste Opening | 2 inches | Varies by fixture count |
| Cleanout Size | 2 inches | Typically larger |
| Additional Requirements | Standard cleanout | May require grease interceptors |
| Hot Water Supply | Standard | ½” supply at 54″ height for chemical feeders codelibrary.amlegal.com |
Commercial kitchens with triple bowl sinks and mop basins face additional requirements, including dedicated hot water supplies for future chemical feeder installations
codelibrary.amlegal.com.
FAQ Section
Q1: Can I use a 1.5-inch cleanout on my kitchen sink drain?
A: No. Illinois plumbing code specifically requires that all residential kitchen sinks have a minimum two-inch (2″) waste opening with a two-inch (2″) cleanout
codelibrary.amlegal.com. Using a smaller cleanout violates code and may fail inspection.
Q2: Do I need a cleanout if my kitchen sink is close to the main drain?
A: If your fixture is within 6 feet of an existing cleanout or drain line connection, a separate cleanout may not be required by code
terrylove.com. However, installing one is still recommended for easier maintenance, especially given the high-clog potential of kitchen drains.
Q3: What happens if my cleanout doesn’t have 18 inches of clearance?
A: Your installation will fail inspection and violate Illinois Plumbing Code Section 890.420(j)
www.law.cornell.edu. You’ll need to modify your cabinetry or relocate the cleanout to provide adequate working space for drain cleaning tools.
Q4: Can I install the cleanout facing downward?
A: No. The code requires cleanouts to open in a direction opposite to the flow of the drainage line or at right angles thereto
www.law.cornell.edu. Downward-facing cleanouts can collect debris and make tool insertion nearly impossible.
Q5: How often should I check my kitchen sink cleanout?
A: While not required by code, inspect your cleanout annually for leaks or corrosion. Test the plug’s seal every 2-3 years by removing and reinstalling it. Replace the gasket if it shows signs of wear or compression.
Q6: Are there penalties for non-compliant cleanout installations?
A: Yes. Non-compliant plumbing work can result in failed inspections, fines, and requirements to redo the work. More importantly, improper installations may void home insurance coverage for related water damage claims.
Conclusion
Understanding the Il Plumbing Code On Cleanout Tees Under Kitchen Sink protects your investment and ensures long-term drainage system functionality. Remember the key requirements: 2-inch minimum size, 18-inch clearance, and proper orientation opposite to flow.
By following these guidelines, you’ll avoid costly corrections, pass inspections smoothly, and maintain easy access for future maintenance. Whether you’re a DIY enthusiast or working with a licensed plumber, these standards keep your kitchen drainage system compliant and efficient.
